EC Centrifugal Fans

RA-ECC190

EC Centrifugal Fans Features:

1. Bearing System: Ball Bearing & Sleeve Bearing

2. Impeller: Pa66 With Fiber Class Filed Ul-94v0

3. Pedestal: Die Cast Aluminum

4. Motor Type: ESM (Energy Saving Motor)

5. Connection: Wire & Terminal

    Blk(+)/(-), Blu(PWM, Custom Service)

6. Protection: Locked (Custom Services)

7.Insulation Class: E

8. Compressive Strength: 1500v

9. Storage Temperature: -20°- 70°

10. Working Temperature: -10°- 60°


Inquire Now
Product Details

RA-ECC190




MODEL NO.VOLTAGE
(V)

 FREQUENCY

  (HZ)

CURRENT
(A)
POWER
(W)
SPEED
(RPM)

MAX AIR FLOW

(CFM)

MAX Sq.
(mm-H2O)
NOISE
(DBA)
RA-ECC190L220  50/600.2026 2300285.00 24.80 63.30
RA-ECC190M220  50/600.34 48 2800 365.0037.30 68.50
RA-ECC190H220  50/600.47 703300 408.00 52.60  72.20


Ruiapple is a Backward Curved Ø 190 mm EC Centrifugal Fans Manufacturer and Supplier in China. Contact us for more custom service information.




1.Other voltage also is realizable  2.Specifications subject to change without notice;  3.Design and provide products according to client’s requirement
