AC Axial Fans

RA-AC12038

AC Axial Fan Features:

1. Bearing System: Ball Bearing & Sleeve Bearing

2. Impeller: PBT With Fiber Class Filed Ul-94v0

3. Housing: Die Casting Aluminum & Surface Black Paint

4. Motor Type: AC Brushless

5. Insulation Class: E

6. Compressive Strength: 1500v

7. Storage Temperature: -20° - 70°

8. Working Temperature: -10° - 60°

Inquire Now
Product Details

Ac axial fan

Ac axial fan

Ac axial fan


MODEL NO.VOLTAGE
(V)

FREUENCY

(HZ)

CURRENT
(A)
POWER
(W)
SPEED
(RPM)

MAX AIR FLOW

(CFM)

MAX Sq.
(mm-H2O)
NOISE
(DBA)
RA-AC12038L22  220/240 50/600.11/0.0911/102200/250071/794.82/5.3337/39
RA-AC12038L11
   110/120 50/60 0.13/0.1211/10 2200/250071/79 4.82/5.3337/39
RA-AC12038M22
   220/240 50/60 0.13/0.1118/17 2700/3000 82/105 5.84/7.1142/47
RA-AC12038M11   110//120 50/60 0.24/0.1818/17 2700/300082/105 5.84/7.11 42/47
RA-AC12038H22
   220/110  50/60  0.14/0.1218/19  2700/3000112/120  6.85/7.62 40/45
RA-AC12038H11   110/120  50/60  0.14/0.1218/19  2700/3000112/120  6.85/7.62 40/45


Description:

This 120x120x38 120mm AC cooling fan could be supplied 110V, 115V, 220V, 230V, 240V voltage, and is housed in die cast aluminum with thermoplastic blades. Has terminal connectors and can be plugged into a standard outlet with a fan power cord, sold separately. Ruiapple fan are certified by CE, UL, and RoHS.


1.Other voltage also is realizable  2.Specifications subject to change without notice;  3.Design and provide products according to client’s requirement
