DC Axial Fans

RA-DC17251A

DC Axial Fans (172x150x51mm) Features:

1. Bearing System: Ball Bearing & Sleeve Bearing

2. Impeller: PBT With Fiber Class Filed Ul-94V0

3. Motor Type: High Performance DC Brushless

4. Connection: Wire & Terminal

                        Red (+) / Black(-) / Blue (PWM)

5. Out Put Signal: FG—Yellow   RD—White

6. Insulation Class: B

7. Compressive Strength: 500v

8. Storage Temperature: -20°---  70°

9. Working Temperature: -10°---  60°

Inquire Now
Product Details

DC Axial fan


Ruiapple as a direct dc fan manufacturer in China, we offer high performance and high efficiency 48V DC axial fan. This moder features 172x150x51 mm and 3 blades.  It is widely applied for many electronics and industrial field. 24V is in option.

MODEL NO.VOLTAGE(V)CURRENT
(A)
POWER
(W)
SPEED(RPM)MAX AIR FLOW(CFM)MAX Sq.
(mm-H2O)
NOISE
(DBA)
RA-DC17251AL12
24
48
0.61
0.35
0.18
 7.32
 8.40
 8.64
2600168.439.8250.60
RA-DC1251AM12
24
48
1.07
0.58
0.28
12.84
13.92
13.44
3200            198.16      14.5556.40
RA-DC17251AH12
24
48
2.08
1.00
0.56
24.96
24.00
26.88
4000             241.13      20.94


62.70





Description:


Related Product:

172x150x51 Fan 5 Blades

View More Products: DC Axial Fans


1.Other voltage also is realizable  2.Specifications subject to change without notice;  3.Design and provide products according to client’s requirement
