DC Blowers

RA-DB9733

Design Features:

1. Bearing System: Ball Bearing & Sleeve Bearing

2. Impeller: PBT With Fiber Class Filed Ul-94v0

3. Housing: Die Cast Aluminum

4. Motor Type: Dc Brushless

5. Connection: Wire & Terminal

              Red (+) / Blk(-) / Blu(PWM)

6. Out Put Signal: Fg—Yell Rd—Wite

7. Protection: Polar & Locked

8. IP Class: Max IP68 )

9. Insulation Class: B

10. Compressive Strength: 500v

11. Storage Temperature: -20°--- 70°

12. Working Temperature: -10°--- 60°

Inquire Now
Product Details

RA-DB9733

RA-DB9733

RA-DB9733


MODEL NO.

VOLTAGE

(V)

CURRENT
(A)
POWER
(W)

SPEED

(RPM)

MAX AIR FLOW

(CFM)

MAX PRESSURE
(mm-H2O)
NOISE
(dBA)
RA-DB9733L12
24
0.22
0.12
2.64
2.88
220016.0012.2040
RA-DB9733M12
24
0.40
0.18
4.80
4.32
300022.0017.8043
RA-DB9733H12
24
0.80
0.41
9.60
9.84
390032.0033.0055



1.Other voltage also is realizable  2.Specifications subject to change without notice;  3.Design and provide products according to client’s requirement
