DC Axial Fans (70x70x10mm) Features:
1. Bearing System: Ball Bearing & Sleeve Bearing
2. Impeller: PBT With Fiber Class Filed Ul-94V0
3. Motor Type: High Performance DC Brushless
4. Connection: Wire & Terminal
Red (+) / Black(-) / Blue (PWM)
5. Out Put Signal: FG—Yellow RD—White
6. Insulation Class: B
7. Compressive Strength: 500v
8. Storage Temperature: -20°--- 70°
9. Working Temperature: -10°--- 60°
| MODEL NO. | VOLTAGE （V) | CURRENT (A) | POWER （W) | SPEED （RPM) | MAX AIR FLOW (CFM) | MAX Sq. （mm-H2O) | NOISE （DBA） |
| RA-DC7010L | 12 24 | 0.18 0.08 | 0.90 0.96 | 8000 | 2.89 | 3.04 | 25.00 |
| RA-DC7010M | 05 12 24 | 0.25 0.10 0.08 | 1.25 1.20 1.92 | 10000 | 3.80 | 5.39 | 32.00 |
| RA-DC7010H | 12 24 | 0.13 0.11 | 1.56 2.64 | 12000 | 4.88 | 6.73 | 36.80 |
Description:
This 12V 7cm 70mm PWM CPU Fan features low noise and long life expectancy, are widely used in network communications, industrial production equipment, computer CPU cooling. Detail dimension 70mmx70mmx10mm. PWM controlled.
Related Product: 70x70x15mm dc fan, 70x70x25mm fan
View More Products: DC Axial Fans
1.Other voltage also is realizable 2.Specifications subject to change without notice; 3.Design and provide products according to client’s requirement
