DC Cooling Fans 50x50x10mm Features:
1. Bearing System: Ball Bearing & Sleeve Bearing
2. Impeller: PBT With Fiber Class Filed Ul-94V0
3. Motor Type: High Performance DC Brushless
4. Connection: Wire & Terminal
Red (+) / Black(-) / Blue (PWM)
5. Out Put Signal: FG—Yellow RD—White
6. Insulation Class: B
7. Compressive Strength: 500v
8. Storage Temperature: -20°--- 70°
9. Working Temperature: -10°--- 60°
| MODEL NO. | VOLTAGE （V) | CURRENT (A) | POWER （W) | SPEED （RPM) | MAX AIR FLOW (CFM) | MAX Sq. （mm-H2O) | NOISE （DBA） |
| RA-DC5010L | 05 12 24 | 0.14 0.08 0.05 | 0.70 0.96 1.20 | 4500 | 6.79 | 1.80 | 30.00 |
| RA-DC5010M | 05 12 24 | 0.20 0.10 0.06 | 1.00 1.20 1.44 | 5500 | 8.94 | 2.61 | 34.20 |
| RA-DC5010H | 12 24 | 0.16 0.09 | 1.92 2.16 | 6500 | 9.83 | 3.53 | 38.80 |
Description:
This Ruiapple 12V 50x50x10 50mm DC brushless cooling fan has been specifically developed to deliver significant airflow while maintaining low noise levels. 5V and 24V voltage are available. This fan provides the performance of a high-end fan at an attractive price, the perfect solution for anyone looking for a quiet, high-performance quality fan. Long-life, high speed, efficient cooling.
Related Product: 50x50x15 cooling fan
View More Products: DC Axial Fans
1.Other voltage also is realizable 2.Specifications subject to change without notice; 3.Design and provide products according to client’s requirement.
