DC Axial Fans (50x50x15mm) Features:
1. Bearing System: Ball Bearing & Sleeve Bearing
2. Impeller: PBT With Fiber Class Filed Ul-94V0
3. Motor Type: High Performance DC Brushless
4. Connection: Wire & Terminal
Red (+) / Black(-) / Blue (PWM)
5. Out Put Signal: FG—Yellow RD—White
6. Insulation Class: B
7. Compressive Strength: 500v
8. Storage Temperature: -20°--- 70°
9. Working Temperature: -10°--- 60°
| MODEL NO. | VOLTAGE （V) | CURRENT (A) | POWER （W) | SPEED （RPM) | MAX AIR FLOW (CFM) | MAX Sq. （mm-H2O) | NOISE （DBA） |
| RA-DC5015L | 12 24 | 0.11 0.06 | 1.32 1.44 | 4500 | 10.05 | 3.23 | 30.10 |
| RA-DC5015M | 12 24 | 0.10 0.07 | 1.20 1.68 | 5500 | 13.60 | 4.68 | 34.20 |
| RA-DC5015H | 12 24 | 0.17 0.10 | 2.04 2.40 | 6500 | 15.90 | 6.39 | 38.30 |
Description:
Available in a variety of voltages, 5v, 12v, 24v, this Ruiapple 50mm 50x50x15 DC cooling fan is designed to replace most 12V 50mm cooling fan, while making only a fraction of the noise. High cfm airflow, higher speeds, longer life and less maintenance. Most used for electronic devices, such as PC computer.
Related Product: 50x50x10mm fan
View More Products: DC Axial Fans
1.Other voltage also is realizable 2.Specifications subject to change without notice; 3.Design and provide products according to client’s requirement
